Recommended Height: 5’1″ ~ 6’1″

• A – total length

  69
• B – handlebar height

  44.5
• C – handlebar length

  28
• D – wheelbase

  45
• E – wheel diameter

  23
• F – minimum seat height

  23.8
• H – chain stay length

  19.7
• L – head tube length

  6.3
• N – standover height

  16.9

• Frame

  6061 Aluminum frame
• Headset

  Neco A16M 44*44*30
• Fork

  WB800-HLO-20″ 28.6*25.4*270mm lockout & preload adjustable
• Shock

  Dual coil spring suspension 290mm
• Front wheel

  Aluminum integrated wheel
• Rear wheel

  Aluminum integrated wheel
• Tires

  Kenda K1188 Krusade 20×4.0
• Battery

  Samsung/LG 48V 15Ah
• Motor

  750W brushless gear motor
• Display

  LCD display with USB charging
• Throttle

  Half twist throttle
• Sensors

  Cadence sensor丨speed sensor丨brake sensor
• Crankset

  Crank arm: 4-jaw L/R forged alloy 170mm | Chain ring: 46T
• Freewheel

  Shimano MF-TZ500-7 14-28T
• Chain

  KMC Z8.3-EPT 120L
• Groupset

  Shimano altus M310 7 speed
• Front brake

  Tektro ARIES MD-M300 mechanical disc brakes
• Rear brake

  Tektro ARIES MD-M300 mechanical disc brakes
• Rotors

  Tektro TR180-24 F:180mm R:180mm

• Stem

  MA-5040 28.6*31.8mm
• Handlebar

  HB-6001 22.2*31.8*710mm
• Saddle

  Himwiay saddle
• Pedal

  Aluminum pedal
• Lights

  48V LED light
• Kickstand

  Heavy-duty aluminum kickstand

• Range

  30-50 miles
• Controller

  48V/22A
• Charger

  US standard 2.0 A smart charger
• Rider height

  5’1″ ~ 6’5″
• Weight

  92lb.(with battery)
• Max. payload capacity

  330 lb.
