Recommended Height:
Cobra — 5’5″ ~ 6’5″
D7 — 5’3″ ~ 6’5″

• A – total length

  82.6
• B – handlebar height

  42.9
• C – handlebar length

  27.6
• D – wheelbase

  51.1
• E – wheel diameter

  30.3
• F – minimum seat height

  30.3
• G – maximum seat height

  37
• H – chain stay length

  19.7
• I – frame stack

  32
• L – head tube length

  5.1
• N – standover height

  30.7

• Frame

  6061 Aluminum frame
• Headset

  Neco H383AEM 28.6*44*56*39.8
• Fork

  DASH-AIR-20 Inverted Fork 120mm lockout & rebound adjustable
• Shock

  DNM A0-38RC rear shock 190*45mm
• Front wheel

  M9CF-150 12G*150*15mm 26” 36h
• Rear wheel

  MD-147 12G 214L 48v 1000w Himiway hub motor
• Tires

  Kenda X Himiway 26*4.5
• Battery

  Samsung/LG 48V 20Ah
• Motor

  1000W brushless gear motor
• Display

  LCD display with Type-c charger
• Throttle

  Thumb throttle
• Sensors

  Torque sensor丨speed sensor丨brake sensor
• Crankset

  Crank arm: EB-01-242A-S1 170mm | Chain ring: 40T 104BCD narrow wide chainring
• Freewheel

  Shimano CS-HG41.8 11-34T
• Chain

  KMC Z8.3 EPT 122L
• Groupset

  Shimano acera M3020 8s
• Front brake

  Tektro HD-E350 hydraulic brake
• Rear brake

  Tektro HD-E350 hydraulic brake
• Rotors

  F:TR-203-52 R:TR-180-52

• Stem

  XF-827 alloy Ext:50mm
• Handlebar

  Promax HB-3188DB -W780
• Seatpost

  SP-2003 30.9*350mm
• Saddle

  Selle royal A054UE
• Pedal

  Aluminum pedal
• Lights

  48V LED light
• Kickstand

  Heavy-duty aluminum kickstand

• Range

  60-80 miles
• Controller

  48V/30A
• Charger

  US standard 3.0 A smart charger
• Rider height

  5′3″ ~ 6′5″
• Weight

  88.6 lb. (with battery)
• Max. payload capacity

  400 lb.
