Recommended Height: 5’3″ ~ 6’5″

• A – total length

  78.7
• B – handlebar height

  47
• C – handlebar length

  28
• D – wheelbase

  49.2
• E – wheel diameter

  28.7
• F – minimum seat height

  20.9
• G – maximum seat height

  31.4
• H – chain stay length

  19
• I – frame stack

  24.6
• J – frame reach

  17.8
• K – effective top tube length

  24.4
• L – head tube length

  5.5
• M – head angle

  65°
• N – standover height

  ST 22.4/ SO 31.1

• Frame

  6061 Aluminum frame
• Headset

  Neco H156EM 28.6*44-56*30
• Fork

  TRAMA 26″”FAT34-26-HLO 95mm travel 9*135mm quick release
• Front wheel

  Rim: MD-147 26*4.0″*36H*12G A/V | Spoke: 12G 255/256L stainless (304M) | Hub: MB015-92 M9*12G*135*145W
• Rear wheel

  Rim: MD-147 26*4.0″”*36H*12G A/V Spoke: 12G 214L stainless (304M) Hub: 48v 750w Himiway hub motor
• Tires

  Kenda 26*4.0
• Battery

  Samsung/LG 48V 20Ah
• Motor

  750W brushless gear motor
• Display

  LCD display with USB charger
• Throttle

  Thumb throttle ¹
• Sensors

  Torque sensor丨speed sensor丨brake sensor
• Crankset

  Crankarm: Prowheel EB-01-242A-S1 170mm | Chain ring: 44T BCD104
• Freewheel

  Shimano MF-TZ500-7 14-28T
• Chain

  KMC Z8.3 EPT 120L
• Groupset

  Shimano altus M310 7 speed
• Front brake

  Tektro HD-E3520 hydraulic brake
• Rear brake

  Tektro HD-E3520 hydraulic brake
• Rotors

  Tektro TR180-52 F:180mm R:180mm

• Stem

  Zoom TDS-C269-8FOV 31.8*90mm
• Handlebar

  Promax HB-3188 22.2*31.8*700mm
• Seatpost

  Himiway Seatpost
• Saddle

  Himiway Saddle
• Pedal

  Aluminum pedal
• Lights

  48V LED light
• Kickstand

  Heavy-duty aluminum kickstand

• Range

  60-80 miles
• Controller

  48V/22A
• Charger

  US standard 3.0 A smart charger
• Rider height

  5′3″ ~ 6′5″
• Weight

  79 lb. (with battery)
• Max. payload capacity

  400 lb.
