Recommended Height: 5’3″ ~ 6’4″

• A – total length

  75
• B – handlebar height

  46.5
• C – handlebar length

  28
• D – wheelbase

  45
• E – wheel diameter

  28.7
• F – minimum seat height

  22
• G – maximum seat height

  29
• H – chain stay length

  18.7
• K – effective top tube length

  23
• L – head tube length

  6.1
• N – standover height

  ST 27.9/ SO 30.3

• Frame

  6061 Aluminum frame
• Headset

  Neco H148 28.6×44*44×30mm
• Fork

  Guide-26”-TNL-95 95mm travel
• Shock

  Alloy front suspension fork with lockout and adjustment
• Front wheel

  MB015-92 13G*135*9mm MD242 26*87mm 12G*36
• Rear wheel

  Rim: 3G*135*9mm MD242 26*87mm | Spoke: 12G*36 | Hub: 48v 750w Himiway hub motor
• Tires

  Kenda 26*4.0
• Battery

  Samsung/LG 48V 15Ah
• Motor

  750W brushless gear motor
• Display

  LCD display with USB charging
• Throttle

  Half twist throttle
• Sensors

  Cadence sensor丨speed sensor丨brake sensor
• Crankset

  Crank arm: 4IXF-212FA 170mm | Chain ring: 46T
• Freewheel

  Shimano MF-TZ500-7 14-28T
• Chain

  KMC Z8.3 EPT 120L
• Groupset

  Shimano altus M310 7 speed
• Front brake

  Tektro ARIES MD-M300 mechanical disc brakes
• Rear brake

  Tektro ARIES MD-M300 mechanical disc brakes
• Rotors

  Tektro TR180-24 F:180mm R:180mm

• Stem

  YC-C410 28.6*80*31.8mm
• Handlebar

  YC-B087 22.2*31.8*700mm
• Seatpost

  H202211DJ ISO-M 30.4*350mm
• Saddle

  TTZ032X
• Pedal

  Aluminum pedal
• Lights

  48V LED light
• Kickstand

  Heavy-duty aluminum kickstand

• Range

  35~60 miles
• Controller

  48V/22A
• Charger

  US standard 2.0 A smart charger
• Rider height

  5’1″ ~ 6’5″
• Weight

  72lb.(with battery)
• Max. payload capacity

  350 lb.
