Recommended Height: 5’4″ ~ 6’3″

• A – total length

  70.8
• B – handlebar height

  48.8
• C – wheelbase

  47
• D – standover height

  31.8
• E – chain stay length

  22.5
• F – frame stack

  31.9
• G – wheel diameter

  23.3
• H – head tube length

  6.7
• I- handlebar length

  26.7
• J – frame reach

  13
• K- head angle

  65°

• Frame

  6061 Aluminum
• Headset

  H115
• Fork

  Dual Crown Steel Rigid Fork
• Tires

  Innova 20×4.0 lA-2149
• Battery

  Samsung/LG 48V 20Ah
• Motor

  48V/750W Rearhub Motor
• Display

  LED Display
• Throttle

  Thumb Throttle
• Sensors

  Cadence Sensor
• Crankset

  142MM Alloy Crankset
• Freewheel

  16T Single Speed
• Chain

  KMC Z1eHX 120L
• Brakes

  Mechanical Brakes

• Stem

  28.6*31.8*40L
• Handlebar

  JY-AL-SMT2,W680*L211*22.2*31.8*10°
• Saddle

  Extended Seat
• Pedal

  0~5 Level Pedal Assist
• Lights

  Integrated Taillight
• Kickstand

  Heavy-duty Aluminum Kickstand

• Range

  60-80 Miles
• Rider height

  5’4″ ~ 6’3″
• Weight

  88 lb.
• Max. system weight

  330 lb.
