Technical Specifications Geometry Recommended Height: 5’3″~6’5″ A – total length 76 B – handlebar height 44 C – handlebar length 27.2 D – wheelbase 48 E – wheel diameter 28.1 F – minimum seat height 24 G – maximum seat height 28.7 H – chain stay length 19.3 I – frame stack 19.2 K – effective top tube length 24 M – head angle 70° N – standover height 21.6 Specification Frame 6061 Aluminum frame Headset TOPYCWZ-5662-01 52*52*39.8 Fork SR-SUNTOUR X1-BOOST 120mm travel Shock DNM AO-06 /165*38mm BK Front wheel Rim: DM-350 27.5″”*13G*36H SV | Spoke: 13G 263L STAINLESS(304M) | Hub: DM41SB-B15 13G*36H*110 Rear wheel Rim: DM-350 27.5″*13G*36H SV | Spoke: 13G 265L STAINLESS(304M) | Hub: M102R-148 12*13*36*148 Tires SCHWALBE SUPER MOTO-X 27.5*2.4 Battery Samsung/LG 48V 15Ah Motor ANANDA M100 48V-500W mid-drive motor Display BIGSTONE M300C-TFT Sensors Torque sensor丨shifting sensor丨speed sensor丨brake sensor Crankset Crank arm: PROWHEEL A00C 170mm 44A-S2-CL41 BCD104 | Chain ring: PROWHEEL 44T 104BCD Narrow wide chainring Cassette Shimano CS-HG201-9 11-34T Chain KMC E9 120L Groupset Shimano M3100SGS ALIVO-9S Front brake Shimano MT200 hydraulic brake Rear brake Shimano MT200 hydraulic brake Rotors Shimano RT26 F:180mm R:180mm Components Stem Promax Alloy ssabk Handlebar MTB-AL-325BT/Φ31.8*/W:680/6° Seatpost ESP-AD635 31.6*350mm | travel:100mm Saddle DDK 153MF Pedal Aluminum pedal Lights 48V LED light Kickstand Heavy-duty aluminum kickstand Others Range 35~50 miles Controller 48V/22A Charger US standard 2.0 A smart charger Rider height 5′3″ ~ 6′5″ Weight 77 lb. Max. payload capacity 300 lb.
Specifications. Frame 6061 Aluminum frame Headset Neco H156EM 28.6*44-56*30 Fork TRAMA FAT34-PLS-26″ 100mm travel 15*135mm thru axle Shock Alloy front suspension fork with lockout and adjustment Front wheel Rim: MD-147 26*4.0″*36H*12G A/V | Spoke: 12G 255/256L stainless (304M) | Hub: MB015-92 M9*12G*135*145W Rear wheel Rim: MD-147 26*4.0″*36H*12G A/V | Spoke: 12G 256/257L stainless (304M) | Hub: GSMB019R-190F-GM14 Tires Kenda 26*4.0 Battery Samsung/LG 48V 20Ah Motor 500W mid-drive motor Display KD718-P LCD display with Type-c charger Throttle Thumb throttle Sensors Torque sensor丨shifting sensor speed sensor丨brake sensor Crankset Crankarm: Prowheel 170mm / Chain ring: 44T BCD104 Freewheel Shimano CS-HG201-9 11-36T Chain KMC E9 EPT 124L Groupset Shimano altus M2000 9 speed Front brake Tektro HD-E3520 hydraulic brake Front brake Tektro HD-E3520 hydraulic brake Rotors Tektro TR180-52 F:180mm R:180mm Components Stem Zoom TDS-C269-8FOV 31.8*90mm Handlebar Promax HB-3188 22.2*31.8*700mm Seatpost Himiway Seatpost Saddle Himiway Saddle Pedal Aluminum pedal Lights 48V LED light Kickstand Heavy-duty aluminum kickstand Others Range 60-80 miles Controller 48V/22A Charger US standard 3.0 A smart charger Rider height 5′3″ ~ 6′5″ Weight 79 lb. (with battery) Max. payload capacity 400 lb.
Technical Specifications Geometry Recommended Height: 5’1″ ~ 6’5″ A – total length 78.7 B – handlebar height 47 C – handlebar length 28 D – wheelbase 49.2 E – wheel diameter 28.7 F – minimum seat height 20.9 G – maximum seat height 31.4 H – chain stay length 19 I – frame stack 24.6 J – frame reach 17.8 K – effective top tube length 24.4 L – head tube length 5.5 M – head angle 65° N – standover height ST 22.4/ SO 31.1 Components Stem Zoom TDS-C269-8FOV 31.8*90mm Handlebar Promax HB-3188 22.2*31.8*700mm Seatpost Himiway Seatpost Saddle Himiway Saddle Pedal Aluminum pedal Lights 48V LED light Kickstand Heavy-duty aluminum kickstand Specification Frame 6061 Aluminum frame Headset Neco H156EM 28.6*44-56*30 Fork TRAMA FAT34-PLS-26″ 100mm travel 15*135mm thru axle Shock Alloy front suspension fork with lockout and adjustment Front wheel Rim: MD-147 26*4.0″*36H*12G A/V | Spoke: 12G 255/256L stainless (304M) | Hub: MB015-92 M9*12G*135*145W Rear wheel Rim: MD-147 26*4.0″*36H*12G A/V | Spoke: 12G 256/257L stainless (304M) | Hub: GSMB019R-190F-GM14 Tires Kenda 26*4.0 Battery Samsung/LG 48V 20Ah Motor 500W mid-drive motor Display KD718-P LCD display with Type-c charger Throttle Thumb throttle 1 Sensors Torque sensor丨shifting sensor speed sensor丨brake sensor Crankset Crankarm: Prowheel 170mm / Chain ring: 44T BCD104 Freewheel Shimano CS-HG201-9 11-36T Chain KMC E9 EPT 124L Groupset Shimano altus M2000 9 speed Front brake Tektro HD-E350 hydraulic brake Rear brake Tektro HD-E350 hydraulic brake Rotors Tektro TR180-52 F:180mm R:180mm Others Range 60-80 miles Controller 48V/22A Charger US standard 3.0 A smart charger Rider height 5’1″ ~ 6’5″ Weight 79 lb. (with battery) Max. payload capacity 400 lb. 1 – Zebra: Half twist throttle
Technical Specifications Geometry Recommended Height: 5’1″ ~ 6’5″ A – total length 78.7 B – handlebar height 47 C – handlebar length 28 D – wheelbase 49.2 E – wheel diameter 28.7 F – minimum seat height 20.9 G – maximum seat height 31.4 H – chain stay length 19 I – frame stack 24.6 J – frame reach 17.8 K – effective top tube length 24.4 L – head tube length 5.5 M – head angle 65° N – standover height ST 22.4/ SO 31.1 Specification Frame 6061 Aluminum frame Headset Neco H156EM 28.6*44-56*30 Fork TRAMA FAT34-PLS-26″ 100mm travel 15*135mm thru axle Shock Alloy front suspension fork with lockout and adjustment Front wheel Rim: MD-147 26*4.0″*36H*12G A/V | Spoke: 12G 255/256L stainless (304M) | Hub: MB015-92 M9*12G*135*145W Rear wheel Rim: MD-147 26*4.0″*36H*12G A/V | Spoke: 12G 256/257L stainless (304M) | Hub: GSMB019R-190F-GM14 Tires Kenda 26*4.0 Battery Samsung/LG 48V 20Ah Motor 500W mid-drive motor Display KD718-P LCD display with Type-c charger Throttle Thumb throttle 1 Sensors Torque sensor丨shifting sensor speed sensor丨brake sensor Crankset Crankarm: Prowheel 170mm / Chain ring: 44T BCD104 Freewheel Shimano CS-HG201-9 11-36T Chain KMC E9 EPT 124L Groupset Shimano altus M2000 9 speed Front brake Tektro HD-E350 hydraulic brake Rear brake Tektro HD-E350 hydraulic brake Rotors Tektro TR180-52 F:180mm R:180mm Components Stem Zoom TDS-C269-8FOV 31.8*90mm Handlebar Promax HB-3188 22.2*31.8*700mm Seatpost Himiway Seatpost Saddle Himiway Saddle Pedal Aluminum pedal Lights 48V LED light Kickstand Heavy-duty aluminum kickstand Others Range 60-80 miles Controller 48V/22A Charger US standard 3.0 A smart charger Rider height 5’1″ ~ 6’5″ Weight 79 lb. (with battery) Max. payload capacity 400 lb. 1 – Zebra: Half twist throttle
Technical Specifications Geometry A – total length 74 B – handlebar height 43.7 C – handlebar length 27.6 D – wheelbase 46.4 E – wheel diameter 28.1 F – minimum seat height 33 G – maximum seat height 38.5 H – chain stay length 18.5 I – frame stack 19.2 K – effective top tube length 22.2 L – head tube length 7.1 N – standover height 18.1 Specification Frame 6061 Aluminum frame Headset Neco H114 44*44*30 Fork TRAMA FSDTOP 30-29HL air spring 80mm travel 9*135mm quick release Shock Alloy front suspension fork with lockout and adjustment Front wheel Rim：MD-239 27.5*36H*13G | Spoke：13G*263L Hub：FH908-ZR Rear wheel Rim：MD-239 27.5*36H*13G | Spoke：13G*261L Hub：RH982-ZR Tires Innova IA-1283 27.5*2.4 Battery Samsung/LG 48V 15Ah Motor 500W mid-drive motor Display LCD display with Type-c charger Throttle Thumb throttle Sensors Torque sensor丨shifting sensor speed sensor丨brake sensor Crankset Crank arm: Bafang 170mm | Chain ring: 38T Cassette Shimano CS-HG201-9 11-36T Chain KMC E9-S EPT 118L Groupset Shimano altus M2000 9 speed Front brake Tektro HD-E350 hydraulic brake Rear brake Nutt Y-5A hydraulic brake Rotors F:180mm R:180mm Components Stem YC-C410 28.6*80*31.8mm Handlebar KW-AL124FOV 22.2*31.8*700MM AL6061 T6 Seatpost SP-C212(ISO-M) 30.4*350 Saddle TTZ032X Pedal Aluminum pedal Lights 48V LED light Kickstand Heavy-duty aluminum kickstand Others Range 40-55 miles Controller 48V/18A Charger US standard 3.0 A smart charger Rider height 5’2″ ~ 6’4″ Weight 61 lb. (with battery) Max. payload capacity 330 lb.
SPECIFICATIONS DOMENSION 2315x1144x1340mm WHEEL BASE 1460 mm GROUND CLEARANCE 250mm WEIGHT 353kg LOADING CAPACITY 240kg FUEL TANK CAPACITY 17L TOP SPEED >80km/h TOWING CAPACITY WEIGHT （TRAILER WITHOUT BRAKE SYSTEM) 250kg TOWING CAPACITY WEIGHT （TRAILER MUST WITH BRAKE SYSTEM) 585kg DIFFERENTIAL & LOCK FRONT AXLE DIFFERENTIAL REAR AXLE WITH DIFFERENTIAL LOCK (OPTION) DRIVING MODE 4WD BRAKING SYSTEM FRONT AND REAR DISC BRAKE SUSPENSION MODE F/R: DOUBLE A-ARM INDEPENDENT SUSPECTION SUSPENSION TYPE F/R: COIL SPRING+OIL DAMPING TYPE TIRE MODE F：25×8-12 R：25×10-12 ENGINE TYPE SINGLE CYLINDER,WATER COOLING, FOUR STORKE, ENGINE BALANCE SHAFT DISPLACEMENT 391 cc BORE * ROUTE 82x74mm MAX POWER/RPM 20kW/6500rpm MAX TORQUE/RPM 30N.m/5000rpm COMPRESSION RATIO 10:01 FUEL SUPPLY MODE ELECTRONIC FUEL INJECTION IGNITION CONTROL MODE ECU TRANSMISSION TYPE CVT / BELT
